Nextion BASIC NX8048T070 7.0″ HMI TFT LCD Touch Display

HMI Displays are becoming increasingly popular as a result of their intelligence, and Nextion is one of the popular brands that only manufactures a Diverse Range of high-quality displays at a comparatively high price. These HMI displays are faster to interact with than other HMI displays because they use high-quality components that set them apart.Nextion HMI Display gain more popularity in the market due to its originality and compatibility in industries and High-end projects also need these types of high-end displays.SpecificationsModel No.NX8048T070Display Type011R(R:Resitive Touchscreen)Operating Voltage (VDC)4.75 ~ 7Max. Operating Current (mA)510Touch TypeResistiveColors65K (65536)Flash Memory16 MBRAM3584 BYTEUSB InterfaceNoMicro-SD Card SlotYes (FAT32 format), support maximum 32G Micro SD CardWorking Temperature Range  (°C)-20 to 70Working Humidity Range10% to 90% RHDisplay Layout Size (L x W x H) mm181 × 108 × 9Net weight (gm)270Shipment Weight0.28 kgFeatures:Compatible with Raspberry Pi A , B , Pi 2, Pi 3, Arduino800 x 480 ResolutionRGB 65K true to life colorsTFT Screen with integrated 4-wire Resistive Touch Panel4 pin TTL serial interface16M Flash memory for User Application Code and DataOnboard micro-SD card slot for firmware upgradationVisual Area: 154.08mm(L)×85.92mm(W)Adjustable Brightness: 0~230 nit, the interval of adjustment is 1%Recommended Power Supply: 5V, 2A, DCCertificates: CE/EMC, RoHS (certificates)Package Includes:1 x Nextion NX8048T070 – Generic 7.0″ HMI TFT LCD Touch Display1 x Connecting Cable1 x Power Supply Test Board
