SY25C 2Pin 7.62mm 20A 300V Barrier Terminal Block Connector – 2 Pcs

Specifications: Type/Design: Barrier Terminal Block (Features an insulating wall between the two terminals) Colour: Black Pitch (Pin Spacing): 7.62 mm This is the center-to-center distance between the two terminal points. Termination Method: Screw Connection Secures the wire by tightening a screw-down clamp. Mounting: PCB Mount (Designed to be soldered onto a Printed Circuit Board) Current Rating: 20 Amperes (20A) Maximum Suitable for moderate to high-current power connections. Voltage Rating: 300 Volts (300V) Maximum (UL Rating) Wire Range (Gauge): Typically 22 – 14 AWG (American Wire Gauge) The recommended range of wire sizes for secure termination. Housing Material: Usually PA66 (Polyamide), meeting UL94 V-0 flame retardant standards. Contact Material: Typically Brass, Tin-plated
