DRV8701ERGER Brushed DC Motor Full-Bridge Gate Driver IC – China

Features: Single H-Bridge Gate Driver – Drives Four External N-Channel MOSFETs – Supports 100% PWM Duty Cycle 5.9-V to 45-V Operating Supply Voltage Range Two Control Interface Options – PH/EN (DRV8701E) – PWM (DRV8701P) Adjustable Gate Drive (5 Levels) – 6-mA to l50-mA Source Current       -12.5-mA to300-mA SinkCurrent Supports L8-V,3.3-V, and S.LVLogicInputs – Current Shunt Amplifier (20 V/V) – Integrated PWM Current Regulation         —Limits Motor Inrush Current Low-Power Sleep Mode (9 A) Two LDO Voltage Regulators to Power External Components AVDD:4.8V,upto30mAOutputLoad DVDD:3.3 V, up to30mA Output Load — Small Package and Footprint 24-Pin QFN(PowerPAD) 4.Ox4.Ox0.gmm Protection Features: VM Undervoltage Lockout(UVLO) Charge Pump Undervoltage(CPUV) Overcurrent Protection(OCP) Pre-driver Fault(PDF) Thermal Shutdown(TSD) Fault Condition Output(nFAULT) Quality: Chinese (if required original, please contact our sales team to [email protected])
