PRODUCT INFORMATION Engine Information EPA and CARB certificated Engine type: 4-stroke, single cylinder, air cooled Displacement: 169cc Max HP: 11hp/8000rpm Max torque: 8.1 lb ft/6000rpm Bore x stroke: 2.4×2.28 inches Climbing ability: 18 degrees Engine oil: SAE 15W-40 Ignition: C.D.I for 200 XRX & ECU for 200E XRX Starting system: Electric Battery: 12V 10Ah Carburetor brand: Deli (Vacuum film) General Information Clutch: Automatic CTV with reverse Driveline / Driving wheel: Chain / Dual wheel drive Suspension, F / R: Double A-arm / swing-arm Brakes, F / R: Both hydraulic brakes, Disc Tires, F / R: 20×7-8 / 22×10-10 Wheel: Aluminum Fuel capacity: 2.25 gal Weight, G.W. / N.W.: 573 / 485 lbs Max load: 500 lbs Dimension Information Wheelbase: 59 inches OA L x W
